Specs
780GC | 780GCA | 780GCB | 780GCC | |
|---|---|---|---|---|
Specifications | ||||
Type | 15’ Triple Flex | 15' Triple Flex | 15' Triple Flex | 15' Triple Flex |
Tractor HP (max.) | 210 HP | 210 HP | 210 HP | 210 HP |
Cutting Width | 180” | 180" | 180" | 180" |
Overall Width | 187” | 187" | 187" | 187" |
Overall Length | 180” | 180" | 180" | 180" |
Hitch | Pull Type | Pull-Type | Pull-Type | Pull-Type |
Driveline Category 540/1000 | PT/CV Joint | PT/CV Joint | PT/CV Joint | PT/CV Joint |
Gearbox Rating (HP) | 255 / 210 HP | 255 / 210 HP | 255 / 210 HP | 255 / 210 HP |
Gearbox Warranty | 5 Years | 5 Years | 5 Years | 5 Years |
Slip Protection | Slip Clutch | Slip Clutch | Slip Clutch | Slip Clutch |
Deck Gauge | 7 Gauge | 7 Gauge | 7 Gauge | 7 Gauge |
Side Panel Depth | 10.5” x 1/4” | 10.5" x 1/4" | 10.5" x 1/4" | 10.5" x 1/4" |
Blade Carrier | Pan | Pan | Pan | Pan |
Output Shaft Diameter | 2” or 2 3/8” | 2" or 2 3/8" | 2" or 2 3/8" | 2" or 2 3/8" |
Blade Size | 1/2” x 4” Updraft | 1/2" x 4" Updraft | 1/2" x 4" Updraft | 1/2" x 4" Updraft |
Blade Tip Speed Center/Out | 15,238 / 14,821 | 15,238 / 14,821 | 15,238 / 14,821 | 15,238 / 14,821 |
Cutting Height (min.) | 2 inch | 2 inch | 2 inch | 2 inch |
Tail Wheel | 3 Spindle | 3 Spindle | 3 Spindle | 3 Spindle |
Tire & Wheel | Laminated | Laminated | 6 tires- 25.75 x 6.75 x 14 (used Aircraft Tires) | 6 tires- 25.75 x 6.75 x 14 (used Aircraft Tires) |
Safety Deflectors | Front/Rear Chains | Front/Rear Chains | Front/Rear Chains | Front/Rear Chains |
Weight (lbs) | 5894 | 5.397 | 5,500 | 5,500 |
