Specs
714GC | 716GC | 717GC | |
|---|---|---|---|
Specifications | |||
Tractor hp (max.) | 48 hp | 48 hp | 48 hp |
Cutting Width | 48" | 60" | 72" |
Overall Width | 53" | 65" | 75" |
Overall Length | 83" | 100" | 106" |
Hitch | 3-point | 3-point | 3-point |
Driveline Category | Category I | Category I | Category I |
Gearbox Rating | 48 hp | 48 hp | 48 hp |
Gearbox Warranty | 2 Years | 2 Years | 2 Years |
Slip Protection | Shear Bolt | Shear Bolt | Shear Bolt |
Deck Gauge | 10 Gauge | 7 Gauge | 7 Gauge |
Side Panel Depth | 8" x 7 Gauge | 8" x 7 Gauge | 8" x 7 Gauge |
Blade Carrier | Pan | Pan | Pan |
Blade Size | 3/8" x 3" Updraft | 3/8" x 3" Updraft | 3/8" x 3" Updraft |
Blade Tip Speed (540) | 13,215 fpm | 16,519 fpm | 14,995 fpm |
Cutting Height (min.) | 1 inch | 1 inch | 1 inch |
Tire & Wheel | Laminated | Laminated | Laminated |
Safety Deflectors | Rubber Belting | Rubber Belting | Rubber Belting |
Weight | 519 lbs. | 781 lbs. | 885 lbs. |
