Specs
63CS | 63CSH | 63CSHB | 72CSH | 74CSHA | 74CSHB | ||
---|---|---|---|---|---|---|---|
Specifications | |||||||
Overall Width | 63" | 63" | 63" | 72" | 63" | 74" | |
Cutting Width | 63" | 63" | 63" | 72" | 74" | 74" | |
Cutting Height | 22" | 22" | 22 1/2" | 26" | 26" | 26" | |
Number of Fan Blades | 4 | 4 | 4 | 4 | 4 | 4 | |
Fan Diameter | 18" | 18" | 17 3/4" | 24" | 24" | 24" | |
Auger Diameter | 14" | 14" | 13 3/4" | 15" | 15" | 15" | |
Fan Drive | #50 HD Chain | n/a | Gear Box Reduction | #60 HD Chain | Gear Box Reduction | Gear Box Reduction | |
Auger Drive | n/a | Gear box reduction | N/A | Gear box reduction | #60 HD Chain | #60 HD Chain | |
Two-Part Chute with | n/a | n/a | n/a | n/a | n/a | n/a | |
Manual Chute Rotation | Standard | Standard | Optional | Standard | Optional | Optional | |
Hydraulic Chute Rotation | Optional | Optional | Standard | Optional | Optional | Standard | |
Electric Chute Rotation | Optional | Optional | Optional | n/a | Optional | Optional | |
Shearbolt Protection | Standard | Standard | Standard | Standard | Standard | Standard | |
Skid Shoe-Std. Adj. | Standard | Standard | Standard | Standard | Standard | Standard | |
Weight | 488 lbs. | 587 lbs. | 1,005 lbs | 807 lbs. | 1,005 lbs | 1,005 lbs |
