Contact us for price

Stock status: Call Store for Availability

THE RIGHT TOOL FOR THE JOB Choose between models with different working widths to match your task and tractor horsepower.

BREAK UP HARD GROUND Up to eight tempered, scarifier shanks provide superior strength and durability for breaking up hard ground.

WORK WITH EASE Any compact or utility tractor with a three-point hitch is Work EZ implement-ready to help you do more for less.

Call Us Now

Specs

48BL
60BL
60BM
72BM
84BM

Specifications

Working Width (ft. (m))
4 (1.2)
5 (1.5)
5 (1.5)
6 (1.8)
7 (2.1)
Overall Height (in. (mm))
35.5 (902)
35.5 (902)
36 (914)
36 (914)
36 (914)
Box Depth (in. (mm))
17 (432)
17 (432)
17 (432)
17 (432)
17 (432)
Max Tractor Horsepower (hp (kW))
30 (22)
35 (26)
50 (37)
50 (37)
60 (45)
Hitch
Category I
Category I
Category I
Category I
Category I
Endplate Thickness (in. (mm))
3/16 (4.8)
3/16 (4.8)
1/4 (6.4)
1/4 (6.4)
1/4 (6.4)
Number of Shanks
4
5
5
6
6
Cutting Edge (in. (mm))
1/2 x 6 (12.7 x 152) Rev.
1/2 x 6 (12.7 x 152) Rev.
1/2 x 6 (12.7 x 152) Rev.
1/2 x 6 (12.7 x 152) Rev.
1/2 x 6 (12.7 x 152) Rev.
Number of cutting edges
2
2
2
2
2
Shank Adjustment
Manual
Manual
Manual
Manual
Manual
Hydraulic Lift
N/A
N/A
N/A
N/A
N/A
Hinged Rear Flap w/ Cut Edge
N/A
N/A
N/A
N/A
N/A
Weight (lbs. (kg))
313 (142)
387 (176)
484 (220)
543 (246)
603 (274)
