New Holland Workmaster™ Compact 25/35/40 Series

Contact us for price

Stock status: Call Store for Availability

Call Us Now

Specs

Engine



Emissions Level
Gross horsepower hp (kW)
Rated speed rpm
No. of cylinders
Aspiration
Displacement cu.in. (L)
Alternator amps
Fuel Tank gal. (L)
Workmaster 25

Workmaster 25
Workmaster 35

Workmaster 35
Workmaster 40

Workmaster 40
T4B Final T4B Final T4B Final
24.7 (18.2) 35 (26.1) 40 (29.2)
2500 2600 2600
3 3 3
Natural Turbo Turbo
80.4 (1.3) 114.7 (1.9) 114.7 (1.9)
50 70 70
7.4 (28) 7.4 (28) 7.4 (28)
PTO



PTO horsepower hp (kW)
PTO speed rpm
PTO type
Mid-PTO
Mid-PTO speed rpm
Workmaster 25

Workmaster 25
Workmaster 35

Workmaster 35
Workmaster 40

Workmaster 40
19.0 (14.1) Gear 17.0 (12.7) HST 29.7 (22.1) Gear / 28.0 (20.9) HST 34.0 (25.4) Gear / 32.0 (23.9) HST
540 540 540
Independent Electro-Hydraulic Engagement Independent Electro-Hydraulic Engagement Independent Electro-Hydraulic Engagement
Optional Optional Optional
2500 2000 2000
Transmission



Type/Control – Choice 1
Type/Control – Choice 2
Maximum forward speed mph (kph)
Cruise control
Gear/shuttle type
Rear differential lock engagement
Brake type
Workmaster 25

Workmaster 25
Workmaster 35

Workmaster 35
Workmaster 40

Workmaster 40
12×12 Gear 12×12 Gear 12×12 Gear
3 Range Hydrostatic/Dual Pedal 3-Range Hydrostatic / Dual Pedal 3-Range Hydrostatic / Dual Pedal
13.8 (22.2) Gear 15.3 (24.7) HST 14.2 (22.9) Gear / 14.8 (23.9) HST 14.2 (22.9) Gear / 14.8 (23.9) HST
Standard HST Standard HST Standard HST
Synchro Synchro Synchro
Mechanical Mechanical Mechanical
Wet, Multi-Disc Wet, Multi-Disc Wet, Multi-Disc
Hydraulics & 3-Point



Implement hydraulic gpm (Lpm)
Steering hydraulic gpm (Lpm)
Total flow gpm (Lpm)
Remote Valves
3-point hitch
3PT lift capacity @ ball ends lb. (kg)
3PT lift capacity @ 24 in. (610 mm) behind ball ends lb. (kg)
3-Point linkage category
Workmaster 25

Workmaster 25
Workmaster 35

Workmaster 35
Workmaster 40

Workmaster 40
7.9 (30) 8.2 (31) 8.2 (31)
4.6 (17.5) Gear 4.6 (17.5) HST 4.2 (15.9) Gear / 5.3 (19.9) HST 4.2 (15.9) Gear / 5.3 (19.9) HST
12.5 (47.5) Gear 12.5 (47.5) HST 12.4 (46.8) Gear / 13.5 (50.8) HST 12.4 (46.8) Gear / 13.5 (50.8) HST
1 or 2 Opt. 1 or 2 Opt. 1 or 2 Opt.
Telescopic Stabilizer /Fixed Link Ends Telescopic Stabilizer / Fixed Link Ends Telescopic Stabilizer / Fixed Link Ends
1808 (820) 1808 (820) 1808 (820)
1433 (650) 1433 (650) 1433 (650)
I | |
Front Axle Options



Two-Wheel Drive
Four-Wheel Drive
Workmaster 25

Workmaster 25
Workmaster 35

Workmaster 35
Workmaster 40

Workmaster 40
N/A N/A N/A
Dimensions/Weight



Wheelbase in. (mm)
Length in. (mm)
Width in. (mm)
Height (top of ROPS or Cab) in. (mm)
Weight lb. (kg)
Workmaster 25

Workmaster 25
Workmaster 35

Workmaster 35
Workmaster 40

Workmaster 40
65.9 (1674) 67.5 (1715) 67.5 (1715)
117.2 (2976) 121 (3074) 121 (3074)
63.7 (1618) 66.5 (1689) 66.5 (1689)
88.2 (2241) 87.7 (2227) 87.7 (2227)
2469 (1120) 3067 (1391) 3067 (1391)
