Specs

Engine*



Engine*
No. of cyl. / Aspiration / Valves
Cylinders / Valves / Displacement cu. in. (L)
Tier 4B / ECOBlue™ HI-eSCR system (Selective Catalytic Reduction)
Approved biodiesel blend**
Max. EPM horsepower @ 1,900 rpm CV hp (kW)
Rated horsepower @ rated RPM per SAE CV hp (kW)
PTO power @ rated 1,811 engine rpm CV hp (kW)
Max. torque – ISO TR14396 lbs. ft. (Nm)
Torque rise %
Viscous coupled cooling fan
Hydraulically driven cooling fan
Automatic exhaust brake
Diesel capacity (Wheeled) gal. (L)
Diesel capacity (Track) gal. (L)
AdBlue tank capacity gal. (L)
Service interval hours
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
FPT Cursor 9 FPT Cursor 13 FPT Cursor 13 FPT Cursor 13 FPT Cursor 13 Two-stage Turbo FPT Cursor 13 Two-stage Turbo FPT Cursor 13 Two-stage Turbo
6/WT/4 6/WT/4 6/WT/4 6/WT/4 6/WT/4 6/WT/4 6/WT/4
6/24/531 (8.7) 6/24/787 (12.9) 6/24/787 (12.9) 6/24/787 (12.9) 6/24/787 (12.9) 6/24/787 (12.9) 6/24/787 (12.9)
B7 B7 B7 B7 B7 B7 B7
425 (317) 462 (345) 517 (386) 550 (410) 605 (451) 638 (476) 682 (509)
370 (276) @ 2,000 rpm 420 (313) @ 2,100 rpm 470 (350) @ 2,100 rpm 500 (373) @ 2,100 rpm 535 (399) @ 2,100 rpm 580 (433) @ 2,100 rpm 620 (462) @ 2,100 rpm
354 (264) 404 (302) 457 (341) 490 (366) 530 (396) 530 (396) 530 (396)
1361 (1845) @ 1400 1469 (1992) @ 1400 1644 (2229) @ 1400 1751 (2374) @ 1400 1873 (2540) @ 1400 2033 (2757) @ 1400 2169 (2941) @ 1400
40 40 40 40 40 40 40
219 (829) 307 (1162) 307 (1162) 307 (1162) 307 (1162) 455 (1722) 455 (1722)
307 (1162) 307 (1162) 307 (1162) 307 (1162) 307 (1162)
42 (159) 42 (159) 42 (159) 42 (159) 66 (250) 66 (250) 66 (250)
600 600 600 600 600 600 600
Ultra Command™ transmission



Ultra Command™ transmission
IntelliShift™ System
Ground Speed Management (GSM)
Number of gears / with Creeper F x R
Min. speed / Max. speed (Wheeled) mph (kph)
Min. speed / Max. speed (Track) mph (kph)
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
16 x 2 16 x 2 16 x 2 16 x 2 16 x 2 16 x 2 16 x 2
2.5/25 (4/40) 2.5/25 (4/40) 2.5/25 (4/40) 2.5/25 (4/40) 2.5/25 (4/40) 2.5/25 (4/40) 2.5/25 (4/40)
2.5/19 (4/31) 2.5/19 (4/31) 2.5/19 (4/31) 2.5/19 (4/31) 2.5/19 (4/31)
Auto Command™ Continuously Variable Transmission



Auto Command™ Continuously Variable Transmission
Powershuttle lever with aggressiveness setting switch
Active StopStart function
Force base propulsion control
Auto Command™ Continuously Variable Transmission (40 kph ECO)
Min. speed / Max. speed (Wheeled) mph (kph)
Min. speed / Max. speed (Track) mph (kph)
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
0.10/25 (0.16/40) 0.10/25 (0.16/40) 0.10 0.10/25 (0.16/40) 0.10/25 (0.16/40) 0.10/25 (0.16/40)
0.10/19 (0.16/31) 0.10/19 (0.16/31) 0.10/19 (0.16/31) 0.10/19 (0.16/31) 0.10/19 (0.16/31)
Configurations



Track Belts in. (mm)
Frame width Wheeled/Track in. (mm)
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
36 (914) Standard Track 36 (914) Standard Track 36 (914) Standard Track 36 (914) Standard Track 36 (914) Standard Track
36.5 (927)/ – 36.5 (927)/ – 36.5 (927)/44 (1118) 36.5 (927)/44 (1118) 44 (1118)/44 (1118) 44 (1118)/44 (1118) 44 (1118)/44 (1118)
Electrical



Alternator/Battery/Electrical Cutoff Switch CCA
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
12 V 200 amp/two 1,000 cranking amps/Yes 12 V 200 amp/two 1,000 cranking amps/Yes 12 V 200 amp/two 1,000 cranking amps/Yes 12 V 200 amp/two 1,000 cranking amps/Yes 12 V 240 amp/two 1,000 cranking amps/Yes 12 V 240 amp/two 1,000 cranking amps/Yes 12 V 240 amp/two 1,000 cranking amps/Yes
Axles



4WD front axle
Articulation angle Wheeled/Standard Tracks degrees
Turning radius in. (mm)
Front & Rear Diff-lock
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
42/ – 42/ – 42/38 42/38 38 38 38
193 (4900) 193 (4900) 193/224 (4900/5690) 193/224 (4900/5690) 224 (5690) 224 (5690) 224 (5690)
Hydraulics



Closed Center Load Sensing (CCLS)
Main pump flow (Standard on full PowerShift)/ High flow option (Standard on CVT) gpm (LPM)
Optional MegaFlow™ II option pump flow Standard / High flow (Total flow available across all remotes) gpm (LPM)
Electronic Draft Control (EDC)
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
40/55 (151/208) 42/57 (159/216) 42/57 (159/216) 42/57 (159/216) 42/57 (159/216) 42/57 (159/216) 42/57 (159/216)
93/108 (351/408) 98/113 (371/428) 98/113 (371/428) 98/113 (371/428) 98/113 (371/428) 98/113 (371/428) 98/113 (371/428)
Remote valves



Type
Max. no. rear valves
Joystick control
Rear linkage
Rear linkage category
Max. lift capacity through the range (610 mm behind ball ends) lbs. (kg)
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
Electro hydraulic Electro hydraulic Electro hydraulic Electro hydraulic Electro hydraulic Electro hydraulic Electro hydraulic
8 8 8 8 8 8 8
IV-N / III IV-N / III IV-N / III IV-N / III IV-N IV-N IV-N
20,000 (9072) 20,000 (9072) 20,000 (9072) 20,000 (9072) 22,750 (10319) 22,750 (10319) 22,750 (10319)
Rear PTO



Rear PTO
Auto Soft Start
Engine speed at 1000 rpm engine rpm
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
1800 1800 1800 1800 1800 1800 1800
Brakes



Automatic exhaust brake
Electronic park brake
Hydraulic trailer brakes
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
Cab



Volume (size) / Glass 132 cu ft/88.1 sq. ft.
360° 4 pillar cab with FOPS – OECD Code 10 Level 1
Cab category level – EN 15695
High visibility RHS window
HID lighting pack
SideWinder™ Ultra armrest
CommandGrip™ handle
Manual adjustment of SideWinder™ Ultra armrest
Air conditioning
Automatic climate control
Air recirculation filters
MP3 Radio with weather channel
Telescopic mirrors
Electronic remotely adjustable mirrors
Comfort Ride™ cab suspension (Standard on track models)
Custom Headland Management (HST II)
A pillar Performance Monitor with enhanced key pad
IntelliView™ IV color monitor with ISO 11783 connector
IntelliSteer™ guidance ready
PLM® Connect Telematics (Telematics components standard. Subscriptions optional)
Optimum cab noise level EC 77/311 dB(A)
Factory fit rotating beacons (1 / 2)
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
2 2 2 2 2 2 2
74 74 74 74 74 74 74
Weights



Wheel Models – Base Shipping Weight lbs. (kg)
Wheel Models – Max Gross Vehicle Weight lbs. (kg)
Track Models – Base and Max Gross Vehicle Weight lbs. (kg)
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
38,571 (17,496) 39,820 (18,062) 39,820 (18,062) 39,820 (18,062) 45,325 (20,559) 49,330 (22,375) 49,330 (22,375)
49,500 (22,453) 49,500 (22,453) 49,500 (22,453) 49,500 (22,453) 56,000 (25,401) 66,000 (29,937) 66,000 (29,937)
63,700 (28,894) 63,700 (28,894) 63,700 (28,894) 63,700 (28,894) 63,700 (28,894)
Dimensions



With rear tire size
Overall length including front weight pack and rear drawbar in. (mm)
Min. width across bar axle in. (mm)
Height at center of rear axle to top of cab in. (mm)
Overall height in. (mm)
Wheelbase in. (mm)
Ground clearance (depends on drawbar) in. (mm)
Width at fenders in. (mm)
T9.435 Wheeled

T9.435 Wheeled
T9.480 Wheeled

T9.480 Wheeled
T9.530 Wheeled and SmartTrax™

T9.530 Wheeled and SmartTrax™
T9.565 Wheeled and SmartTrax™

T9.565 Wheeled and SmartTrax™
T9.600 Wheeled and SmartTrax™

T9.600 Wheeled and SmartTrax™
T9.645 Wheeled and SmartTrax™

T9.645 Wheeled and SmartTrax™
T9.700 Wheeled and SmartTrax™

T9.700 Wheeled and SmartTrax™
710/70R42 – Singles 710/70R42 – Singles 710/70R42 – Singles 710/70R42 – Singles 710/70R42 – Singles 710/70R42 – Singles 710/70R42 – Singles
291.0 (7393) 291.0 (7393) 291.0 (7393) 291.0 (7393) 291.0 (7393) 299.8 (7615) 299.8 (7615)
120.0 (3048) 120.0 (3048) 120.0 (3048) 120.0 (3048) 120.0 (3048) 120.0 (3048) 120.0 (3048)
110.0 (2794) 110.0 (2794) 110.0 (2794) 110.0 (2794) 110.0 (2794) 114.2 (2903) 114.2 (2903)
151.3 (3843) 151.3 (3843) 151.3 (3843) 151.3 (3843) 151.3 (3843) 156.0 (3963) 156.0 (3963)
147.9 (3759) 147.9 (3759) 147.9 (3759) 147.9 (3759) 147.9 (3759) 153.9 (3911) 153.9 (3911)
17.4 (443) 17.4 (443) 17.4 (443) 17.4 (443) 17.4 (443) 17.6 (447) 17.6 (447)
100.35 (2549) 100.35 (2549) 100.35 (2549) 100.35 (2549) 100.35 (2549) 100.35 (2549) 100.35 (2549)
