Specs
60CBH | 72CBH | |
|---|---|---|
Specifications | ||
Moldboard width (in. (mm)) | 60 (1524) | 72 (1829) |
Moldboard height (in. (mm)) | 22 (559) | 22 (559) |
Moldboard thickness (in. (mm)) | 1/4 (6.4) | 1/4 (6.4) |
Cutting edge thickness (in. (mm)) | 1/2 (12.7) | 1/2 (12.7) |
Cutting edge height (in. (mm)) | 6 (152) | 6 (152) |
Reversible cutting edge | Standard | Standard |
Blade lift height (in. (mm)) | 8 (203) | 9.5 (241) |
Digging depth (in. (mm)) | 6.5 (165) | 9.5 (241) |
Max blade angle (degrees) | 30 | 30 |
Adjustable skid shoes | Standard | Standard |
Quick Attach | Yes | Yes |
Manual angle | N/A | N/A |
Hydraulic angle | Standard | Standard |
Weight (lbs. (kg)) | 399 (181) | 540 (245) |
