Specs
| Model | Description | MSRP |
|---|---|---|
| STCII-48V-23CV | 48″ Velocity Plus™ Cutter Deck, 23 HP Kohler® Command PRO® | $12,165 |
| STCII-48V-22FX | 48″ Velocity Plus™ Cutter Deck, 22 HP Kawasaki® 691FX | $12,299 |
| STCII-52V-24FT | 52″ Velocity Plus™ Cutter Deck, 24 HP Kawasaki® FT Series | $12,499 |
| STCII-52V-28BV-EFI | 52″ Velocity Plus™ Cutter Deck, 28 HP Briggs Vanguard™ 810 – electronic fuel injection | $12,499 |
| STCII-52V-26FT-EFI | 52″ Velocity Plus™ Cutter Deck, 26 HP Kawasaki® 730FT – electronic fuel injection | $12,582 |
| STCII-52V-25CV-EFI | 52″ Velocity Plus™ Cutter Deck, 25 HP Kohler® Command PRO® – electronic fuel injection | $12,765 |
| STCII-52V-23FX | 52″ Velocity Plus™ Cutter Deck, 23 HP Kawasaki® FX Series | $12,832 |
| STCII-61V-26FT-EFI | 61″ Velocity Plus™ Cutter Deck, 26 HP Kawasaki® 730FT – electronic fuel injection | $12,832 |
| STCII-61V-26CV-EFI | 61″ Velocity Plus™ Cutter Deck, 26 HP Kohler® Command PRO® – electronic fuel injection | $13,165 |
| STCII-61V-32BV | 61″ Velocity Plus™ Cutter Deck, 32 HP Briggs Vanguard™ BIG BLOCK™ | $13,332 |
| Specification | Tiger Cat | |
|---|---|---|
| General | Total Fuel Capacity | 9.5 gallons |
| Drive Tires | 24″ x 9.5″-12″ (48″ and 52″)
24″ x 12″-12″ (61″) |
|
| Caster Tires | 13″ x 6.5″-6″, flat-free | |
| Seat | 4-point iso-mounted mid-back mounted on operator-suspension platform | |
| Drive System | Drive System Type | Dual Pump and Motor |
| Pumps | Hydro-Gear 12 cc | |
| Motors | Parker 14.5 ci | |
| Forward Ground Speed | 12 mph | |
| Reverse Ground Speed | 5 mph | |
| Parking Brake | Foot-operated pedal | |
| Deck | Cutting Widths | 48″, 52″ and 61″ |
| Type | Velocity Plus™ | |
| Cutting Height | 1″ to 5″ in .25″ increments | |
| Deck Lift | Adjustable foot-operated pedal | |
| Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. | |
| Spindles | Cast-iron housing with tapered roller bearings. | |
| Blade Engagement | Ogura GT3.5 (250 ft lb)
Adjustable air-gap for extended life. |
