Specs
Model | Deck Width | Engine | Horsepower | MSRP |
---|---|---|---|---|
STCII-48V-22FX | 48″ | Kawasaki® FX Series | 22 | $12,819 |
STCII-48V-23CV ![]() | 48″ | Kohler® Command PRO® | 23 | $11,729 |
STCII-52V-25CV-EFI ![]() | 52″ | Kohler® Command PRO® EFI – electronic fuel injection | 25 | $12,599 |
STCII-52V-26FT-EFI | 52″ | Kawasaki® FT Series – electronic fuel injection | 26 | $13,399 |
STCII-52V-28BV-EFI | 52″ | Vanguard™ EFI – electronic fuel injection | 28 | $13,119 |
STCII-52V-36BV ![]() | 52″ | Vanguard™ BIG BLOCK™ | 36 | $14,179 |
STCII-61V-26CV-EFI ![]() | 61″ | Kohler® Command PRO® EFI – electronic fuel injection | 26 | $13,499 |
STCII-61V-26FT-EFI | 61″ | Kawasaki® FT Series EFI – electronic fuel injection | 26 | $13,779 |
STCII-61V-36BV ![]() | 61″ | Vanguard™ BIG BLOCK™ | 36 | $14,349 |
Contact your local Scag dealer for specific availability information. |
Product Dimensions | 48″ Tiger Cat | 52″ Tiger Cat | 61″ Tiger Cat |
---|---|---|---|
Length | 80″ | 80″ | 80″ |
Width (chute down) | 60.5″ | 64.5″ | 73.5″ |
Width (chute in transport position) | 49.75″ | 53.75″ | 62.75″ |
Height (ROPS folded) | 46.75″ | 46.75″ | 46.75″ |
Height (ROPS up) | 67.25″ | 67.25″ | 67.25″ |
Weight | 1,175 lb | 1,175-1,180 lb | 1,257-1,277 lb |
General | |
---|---|
Total Fuel Capacity | 9.5 gallons |
Drive Tires | 24″ x 9.5″-12″ (48″ and 52″) 24″ x 12″-12″ (61″) |
Caster Tires | 13″ x 6.5″-6″, flat-free |
Seat | 4-point iso-mounted mid-back mounted on operator-suspension platform |
Drive System | |
Drive System Type | Dual Pump and Motor |
Pumps | Hydro-Gear 12 cc |
Motors | Parker 14.5 ci |
Forward Ground Speed | 12 mph |
Reverse Ground Speed | 5 mph |
Parking Brake | Foot-operated pedal |
Deck | |
Cutting Widths | 48″, 52″ and 61″ |
Type | Velocity Plus™ |
Cutting Height | 1″ to 5″ in .25″ increments |
Deck Lift | Adjustable foot-operated pedal |
Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. |
Spindles | Cast-iron housing with tapered roller bearings. |
Blade Engagement | Adjustable air-gap for extended life. |
