New Holland Workmaster™ Utility 50 – 70 Series

Contact us for price

Stock status: Call Store for Availability

Call Us Now

Specs

Engine



Make
# Cylinders / Aspiration
Displacement [cu.in (L)]
Gross engine power [hp (kW)]
PTO horsepower [hp (kW)]
Rated speed (rpm)
Fuel type
Air Filter
Standards
Fuel tank capacity [gal (L)]
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
FPT – R753 FPT – R753 FPT – R753 FPT – R753 FPT – R753 FPT – R753
3, Turbo 3, Turbo 3, Turbo 3, Turbo 3, Turbo 3, Turbo
136 (2.2) 136 (2.2) 136 (2.2) 136 (2.2) 136 (2.2) 136 (2.2)
53 (39.5) 53 (39.5) 60 (45) 60 (45) 70 (52) 70 (52)
45 (34) 45 (34) 51 (38) 51 (38) 62 (46) 62 (46)
2600 2600 2600 2600 2600 2600
Direct Injection /Common Rail Direct Injection /Common Rail Direct Injection /Common Rail Direct Injection /Common Rail Direct Injection /Common Rail Direct Injection /Common Rail
2 – stage 2 – stage 2 – stage 2 – stage 2 – stage 2 – stage
4B final 4B final 4B final 4B final 4B final 4B final
17.2 (65) 17.2 (65) 17.2 (65) 17.2 (65) 17.2 (65) 17.2 (65)
Transmission



Traction clutch
8×8 synchro shuttle
Standard Rear Tire
Optional Rear Tire
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
Dry, 11″ (279.4 mm) diameter, organic plate Dry, 11″ (279.4 mm) diameter, organic plate Dry, 11″ (279.4 mm) diameter, organic plate Dry, 11″ (279.4 mm) diameter, organic plate Dry, 11″ (279.4 mm) diameter, organic plate Dry, 11″ (279.4 mm) diameter, organic plate
8Fx8R Synchronized Shuttle with synchronized gears and non-synchronized ranges 8Fx8R Synchronized Shuttle with synchronized gears and non-synchronized ranges 8Fx8R Synchronized Shuttle with synchronized gears and non-synchronized ranges 8Fx8R Synchronized Shuttle with synchronized gears and non-synchronized ranges 8Fx8R Synchronized Shuttle with synchronized gears and non-synchronized ranges 8Fx8R Synchronized Shuttle with synchronized gears and non-synchronized ranges
13.6-28 (R1) 13.6-28 (R1) 14.9-28 (R1) 14.9-28 (R1) 14.9-28 (R1) 14.9-28 (R1)
18.4-24 (R4), FWD 18.4-24 (R4), FWD 18.4-24 (R4), FWD 18.4-24 (R4), FWD 18.4-24 (R4), FWD 18.4-24 (R4), FWD
Brakes



Service brakes
Parking brake
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
Mechanical multi-plate wet disc Mechanical multi-plate wet disc Mechanical multi-plate wet disc Mechanical multi-plate wet disc Mechanical multi-plate wet disc Mechanical multi-plate wet disc
Engage hard-lever, press brake pedals to lock service brakes Engage hard-lever, press brake pedals to lock service brakes Engage hard-lever, press brake pedals to lock service brakes Engage hard-lever, press brake pedals to lock service brakes Engage hard-lever, press brake pedals to lock service brakes Engage hard-lever, press brake pedals to lock service brakes
Rear Axle



Rear differential lock
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
Mechanical foot pedal engagement Mechanical foot pedal engagement Mechanical foot pedal engagement Mechanical foot pedal engagement Mechanical foot pedal engagement Mechanical foot pedal engagement
Front Axle



FWD clutch engagement
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
Mechanical, FWD Mechanical, FWD Mechanical, FWD Mechanical, FWD Mechanical, FWD Mechanical, FWD
Hydraulics



System type
Implement pump capacity [gpm (lpm)]
Steering & services system [gpm (lpm)]
Total maximum tractor flow [gpm (lpm)]
Remote valves
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
Open center, fixed displacement gear pump Open center, fixed displacement gear pump Open center, fixed displacement gear pump Open center, fixed displacement gear pump Open center, fixed displacement gear pump Open center, fixed displacement gear pump
12 (45) 12 (45) 12 (45) 12 (45) 12 (45) 12 (45)
5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21) 5.5 (21)
17.5 (66) 17.5 (66) 17.5 (66) 17.5 (66) 17.5 (66) 17.5 (66)
Open center, float detent available for #1, #2 FIO or DIA Open center, float detent available for #1, #2 FIO or DIA Open center, float detent available for #1, #2 FIO or DIA Open center, float detent available for #1, 1 or 2 FIO or DIA Open center, float detent available for #1, 1 or 2 FIO or DIA Open center, float detent available for #1, 1 or 2 FIO or DIA
Rear 3-point hitch



Category
Position control, draft sensing
OECD lift capacity @ 24″ behind ball ends [lbs (kg)]
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
II/I II/I II/I II/I II/I II/I
One lever, standard mechanical draft control One lever, standard mechanical draft control One lever, standard mechanical draft control One lever, standard mechanical draft control One lever, standard mechanical draft control One lever, standard mechanical draft control
2,701 (1225) 2,701 (1225) 2,701 (1225) 2,701 (1225) 2,701 (1225) 2,701 (1225)
PTO type



PTO type
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
Independent Mechanical Engagement Independent Mechanical Engagement Independent Mechanical Engagement Independent Mechanical Engagement Independent Mechanical Engagement Independent Mechanical Engagement
Rear PTO



Rear PTO
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
540 RPM Standard / 540/540E Economy optional 540 RPM Standard / 540/540E Economy optional 540 RPM Standard / 540/540E Economy optional 540 RPM Standard / 540/540E Economy optional 540 RPM Standard / 540/540E Economy optional 540 RPM Standard / 540/540E Economy optional
Electrical



Alternator
Battery capacity (cold cranking amps)
Lighting
Accessory power outlets
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
75 75 75 75 75 75
720 720 720 720 720 720
2 halogen headlights, 2 halogen corning worklights, flashing safety lights/turn signals 2 halogen headlights, 2 halogen corning worklights, flashing safety lights/turn signals 2 halogen headlights, 2 halogen corning worklights, flashing safety lights/turn signals 2 halogen headlights, 2 halogen corning worklights, flashing safety lights/turn signals 2 halogen headlights, 2 halogen corning worklights, flashing safety lights/turn signals 2 halogen headlights, 2 halogen corning worklights, flashing safety lights/turn signals
Standard equipment, 7-pin implement outlet Standard equipment, 7-pin implement outlet Standard equipment, 7-pin implement outlet Standard equipment, 7-pin implement outlet Standard equipment, 7-pin implement outlet Standard equipment, 7-pin implement outlet
General



ROPS
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
Foldable Foldable Foldable Foldable Foldable Foldable
Dimensions



Shipping length [in (mm)]
Shipping width [in (mm)]
Shipping height [in (mm)]
Shipping weight [lbs (kg)]
WORKMASTER™ 50 2WD

WORKMASTER™ 50 2WD
WORKMASTER™ 50 4WD

WORKMASTER™ 50 4WD
WORKMASTER™ 60 2WD

WORKMASTER™ 60 2WD
WORKMASTER™ 60 4WD

WORKMASTER™ 60 4WD
WORKMASTER™ 70 2WD

WORKMASTER™ 70 2WD
WORKMASTER™ 70 4WD

WORKMASTER™ 70 4WD
129.5 (3290) 134 (3404) 129.5 (3290) 134 (3404) 129.5 (3290) 134 (3404)
77.5 (1970) 77.5 (1970) 77.5 (1970) 77.5 (1970) 77.5 (1970) 77.5 (1970)
97.6 (2479) 97.6 (2479) 97.6 (2479) 97.6 (2479) 97.6 (2479) 97.6 (2479)
4,442 (2015) 5,059 (2995) 4,442 (2015) 5,059 (2995) 4,442 (2015) 5,059 (2995)
