New Holland COMPACT TRACK LOADERS

Contact us for price

Stock status: Call Store for Availability

Call Us Now

Specs

Overall operating height



Overall operating height with foundry/excavating bucket short lip in (mm)
Overall operating height with low profile/standard lip bucket in (mm)
Overall operating height with low profile extended/long lip bucket in (mm)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
155.6 (3953) 157.2 (3993) 160.2 (4068) 160.2 (4068) 161.4 (4100) NA
159.8 (4059) 161.4 (4099) 164.4 (4176) 164.4 (4176) 165.6 (4207) 176.5 (4483)
164.6 (4148) 166.2 (4221) 169.2 (4298) 169.2 (4298) 170.4 (4329) 189.6 (4816)
Height to



Bucket hinge pin in (mm)
Top of ROPS in (mm)
Bottom of level bucket, fully raised in (mm)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
125 (3178) 126.5 (3215) 131.1 (3330) 131.1 (3330) 131.6 (3342) 140.2 (3562)
78.7 (1998) 80.4 (2043) 80.4 (2043) 80.4 (2043) 80.4 (2043) 84.6 (2150)
117.1 (2976) 118.7 (3016) 123.0 (3125) 123.0 (3125) 123.2 (3129) 133.3 (3386)
Overall length



Overall length without attachment with coupler in (mm)
Overall length with foundry excavation bucket on ground in (mm)
Overall length with low profile bucket in (mm)
Overall length with low profile extended bucket in (mm)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
104.8 (2662) 118.2 (3003) 117.3 (2979) 117.0 (2972) 120.2 (3054) 129.5 (3290)
129.6 (3292) 142.6 (3621) 141.7 (3598) 141.1 (3592) 144.6 (3673) NA
133.4 (3388) 141.5 (3749) 147 (3734) 146.7(3727) 148.8 (3781) 159.1 (4041)
138.3 (3512) 151.7 (3853) 150.8 (3830) 150.5 (3823) 153.7 (3904) 172.7 (4386)
Dump



Dump angle degrees
Dump height with foundry/excavating bucket short lip in (mm)
Dump height with low profile/standard lip bucket in (mm)
Dump reach (max height) in (mm)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
38.1 38.1 55 55 45.3 46.1
100.6 (2556) @ 38.1° 102.4 (2602) @ 38.3° 104.5 (2655) @ 45° 104.5 (2655) @ 45° 104.1 (2645) @ 45° 109 (2768)
98.0 (2488) @ 38.1° 99.9 (2537) @ 38.1° 101.6 (2581) @ 45° 101.6 (2581) @ 45° 101.1 (2568) @ 45° 99.2 (2519)
22.3 (568) @ 38.1° 21.6 (548) @ 38.1° 37 (941) @ 45° 37 (941) @ 45° 31.6 (802) @ 45° 39 (990)
Maximum attachment rollback



Bucket on ground degrees
Bucket at full height degrees
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
31 30.6 33 33 32 30
99 100 85 85 83.1 84
Track and clearance



Track on ground in (mm)
Ground clearance (bottom of belly pan) in (mm)
Angle of departure degrees
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
55.9 (1419) 64.5 (1639) 64.5 (1639) 64.5 (1639) 64.5 (1639) 66 (1677)
8 (203) 9.6 (243) 9.6 (244) 9.6 (244) 9.6 (244) 12.6 (321)
32 32 32 32 32 38
Clearance circle



Clearance circle without bucket in (mm)
Clearance circle with foundry bucket in carry position in (mm)
Clearance circle with low profile bucket on ground in (mm)
Clearance circle with extended low profile on ground in (mm)
Clearance circle rear in (mm)
Track guage in (mm)
Overall width in (mm)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
52.3 (1346) 57.7 (1466) 56.2 (1482) 56.2 (1482) 57.7 (1465) 67.4 (1712)
82.2 (2187) with 72″ bucket 87 (2210) with 78” bucket 86.6 (2200) with 78” bucket 86.6 (2200) with 78” bucket 88 (2234) with 78″ bucket NA
85.8 (2181) with 72″ bucket 90.8 (2307) with 78” bucket 90.4 (2297) with 78” bucket 90.4 (2297) with 78” bucket 91.8 (2331) with 78″ bucket NA
90.4 (2297) with 72″ bucket 95.2 (2419) with 78” bucket 94.8 (2409) with 78” bucket 94.8 (2409) with 78” bucket 96.2 (2444) with 78″ bucket NA
59.1 (1501) 67.9 (1725) 67 (1702) 67 (1702) 67.9 (1725) 114 (2913)
53.4 (1356) 58.3 (1480) 58.6 (1488) 58.6 (1488) 58.6 (1488) NA
65.9 (1676) 76.5 (1943) 76.5 (1943) 76.5 (1943) 76.5 (1943) 78.3 (1988)
Engine



Manufacturer/model
Type
Cylinder
Bore/stroke in (mm)
Displacement in3 (L)
Fuel injection
Fuel
Fuel filter
Air intake
Cooling
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
FPT / F5H FL463A FPT / F5BFL413E*B002 FPT / F5H FL463A*G001 FPT / F5BFL463A*G001 FPT / F5BFL413E*B002* FPT / F5BFL413D*C005
Diesel 4-stroke, turbo, D.I. Diesel 4-stroke, turbo, D.I. Diesel 4-stroke, turbo, D.I. Diesel 4-stroke, turbo, D.I. Diesel 4-stroke, turbo, D.I. Diesel, 4-stroke, turbo, D.I.
4 4 4 4 4 4
3.9 x 4.3 (99 x 109) 3.9 x 4.3 (99 x 110) 3.9 x 4.3 (99 x 110) 3.9 x 4.3 (99 x 110) 3.9 x 4.3 (99 x 110) 3.9 x 4.3 (99 x 110)
207 (3.4) 207.5 (3.4) 207 (3.4) 207.5 (3.4) 207 (3.4) 207 (3.4)
HPCR Direct HPCR Direct HPCR Direct HPCR Direct HPCR Direct HPCR Direct
#2 diesel #2 diesel #2 diesel #2 diesel #2 diesel #2 diesel
Pre-spin on 30 microns Main-spin on 4 microns Pre-filter 99.8% @ 30 microns Main filter 95% @ 4 microns Pre-spin on 30 microns Main-spin on 4 microns Pre-filter 99.8% @ 30 microns, Main filter 95% @ 4 microns Pre-filter 99.8% @ 30 microns, Main filter 95% @ 4 microns Pre-filter Spin on, Beta(30) = 200, Main filter Spin on, Beta(4) > 50, Beta(6) > 200
Turbocharged with external EGR Turbocharged Aftercooled with external EGR and SCR Turbocharged Aftercooled with external EGR Turbocharged Aftercooled with external EGR Turbocharged Aftercooled with external EGR and SCR Turbocharged Aftercooled with external EGR and SCR
Liquid Liquid Liquid Liquid Liquid Liquid
Engine speeds



High idle – no load rpm
Rated – full load rpm
Low idle rpm
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
2500 +/- 25 2500 +/- 25 2500 +/- 25 2500 +/- 25 2500 +/- 25 2500 +/- 25
2500 2500 2500 2500 2500 2500
1150 +/- 25 1150 +/- 25 1150 +/- 25 1150 +/- 25 1150 +/- 25 1150 +/- 50
Horsepower per SAE J1349



Gross hp (kW)
Net hp (kW)
Peak torque lb-ft (N•m)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
74 (55) @ 2500 rpm 90 (67) @ 2500 rpm 74 (55) @ 2500 rpm 74 (55) @ 2500 rpm 90 (67) @ 2500 rpm 114 (85) @ 2500
68 (51) @ 2500 rpm 84 (63) @ 2500 rpm 68 (51) @ 2500 rpm 68 (51) @ 2500 rpm 84 (63) @ 2500 rpm 114 (85) @ 2500
232 (314) @ 1400 rpm 282 (383) @ 1400 rpm 232 (314) @ 1400 rpm 232 (314) @ 1400 rpm 282 (383) @ 1400 rpm 339 (460) @ 1400
Drive pump electro hydraulic



Pump to engine ratio
Displacement in3 (cc)
Flow gpm (Lpm)
Charge pressure psi (bar)
System relief psi (bar)
Control
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
1:1 1:1 1:1 1:1 1:1 1:1
2.75 (45) 2.75 (45) 2.75 (45) 2.75 (45) 2.75 (45) 49.1 (3)
24.2 (91.5) 28.8 (109) 24.2 (91.5) 28.8 (109) 29.4 (111) 40 (10.5)
362 (24.5) 362 (25) 362 (24.5) 362 (24.5) 360 (24.5) 377 (26)
5220 (360) 5220 (360) 5220 (360) 5220 (360) 5220 (360) 5802 (400)
Mechanical or Electro hydraulic Electro hydraulic Electro hydraulic Mechanical or Electro hydraulic Mechanical or Electro hydraulic Mechanical or Electro hydraulic Electro hydraulic
Drive motors



Effective Max displacement in3 (cc)
Effective Displacement opt high speed in3 (cc)
Speed @ high idle engine rpm
Speed @ optional high speed rpm
Torque @ max displ. and relief pressure lb-ft (N•m)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
67 (1098) 67 (1098) 3.10 (50.9) 3.10 (50.9) 3.10 (50.9) 3.28 (53.8)
43.6 (714) 43.6 (714)
103 103 103 103 103 50
156 156 156 156 156 100
4654 (6310) 3027 (4104) 4654 (6310) 4654 (6310) 4654 (6310) 4840 (6562)
Travel speed



Low range mph (km/h)
High range
Final drive
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
5.5 (8.9) 5.5 (8.2) 5.5 (8.9) 5.5 (8.9) 5.5 (8.9) 5 (8)
8.0 (12.9) 8.0 (12.9) 8.0 (12.9) 8.0 (12.9) 8.0 (12.9) 8.7 (14)
Planetary gearbox with 2-speed motor Planetary gearbox with 2-speed motor Planetary gearbox with 2-speed motor Planetary gearbox with 2-speed motor Planetary gearbox with 2-speed motor Planetary gearbox with 2-speed motor
Parking brake



Type
Engagement
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
Spring applied, hydraulic release disc Spring applied, hydraulic release disc Spring applied, hydraulic release disc Spring applied, hydraulic release disc Spring applied, hydraulic release disc Spring applied, hydraulic released multi plet wet disc
Depress on/off brake button on instrument panel, disconnect lapbelt, get off seat, or stop engine Depress on/off brake button on instrument panel, disconnect lapbelt, get off seat, or stop engine Depress on/off brake button on instrument panel, disconnect lapbelt, get off seat, or stop engine Depress on/off brake button on instrument panel, disconnect lapbelt, get off seat, or stop engine Depress on/off brake button on instrument panel, disconnect lapbelt, get off seat, or stop engine Depress on/off brake button on instrument panel, disconnect lapbelt, get off seat, or stop engine
Undercarriage



System
Idlers / rollers per side
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
Zig Zag Pattern Zig Zag Pattern Zig Zag Pattern Zig Zag Pattern Zig Zag Pattern H-Pattern
2/3 2/4 2/4 2/4 2/4 2/6
Ground pressure



PSI (with spec belt)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
5.9 4.2 4.2 4.2 4.4 6.1
Pumps



Type
Displacement standard aux. in3 (cc)
Displacement high flow aux. in3 (cc)
Standard pump flow gpm (Lpm)
Optional high flow gpm (Lpm)
Enhanced high flow gpm (Lpm)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
Gear Gear Gear Gear Gear Tandem Pump, Integral
2.23 (36.6) 2.23 (36.6) 2.23 (36.6) 2.23 (36.6) 2.23 (36.6) 3.7 (60)
.76 (12.5) 1.24 (20.4) 1.24 (20.4) 1.24 (20.4) 1.45 (23.7) 3.7 (60)
24.2 (91.5) 24.2 (91.5) 24.2 (91.5) 24.2 (91.5) 24.2 (91.5) 10.5 (40)
32.4 (122.6) 37.6 (142.5) 37.6 (142.5) 37.6 (142.5) 39.9 (150.8) 41.6
NA 35 (132.5) NA NA 35 (132.5) 41.6
Loader control valve



Type
Standard relief pressure psi (bar)
Enhanced high flow relief pressure psi (bar)
Hydraulic filter
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
3 spool / open center / series 3 spool / open center / series 3 spool / open center / series 3 spool / open center / series 3 spool / open center / series 3 spool / closed-center load sensing
3046 (210) 3046 (210) 3,046 (210) 3,046 (210) 3,450 (237) 3,450 (237)
NA 4000 (276) NA NA 4000 (276) 4100 (283)
6 microns / spin on 6 microns / spin on 6 microns / spin on 6 microns / spin on 6 microns / spin on 6 microns / spin on
Lift cylinder



Bore diameter in (mm)
Rod diameter, in (mm) in (mm)
Stroke in, in (mm) in (mm)
Closed length, in (mm) in (mm)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
2.5 (63.5) 2.75 (69.85) 2.5 (63.5) 2.75 (69.85) 2.75 (69.8) 3.25 (82.5)
1.75 (44.5) 2.0 (50.8) 1.75 (44.5) 1.75 (44.5) 1.75 (44.5) 2.25 (57.1)
31.69 (804.9) 33.4 (847.9) 33.5 (851.9) 34.9 (886.5) 35.7 (908) 38.8 (985)
45.59 (1158.0) 47.1 (1196) 46.9 (1192) 47.4 (1205) 53.9 (1369.1) 59.6 (1515)
Bucket cylinders



Bore diameter, in (mm) in (mm)
Rod diameter, in (mm) in (mm)
Stroke, in (mm) in (mm)
Closed length, in (mm) in (mm)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
2.75 (69.9) 3.9 (99) 3.0 (76.2) 3.0 (76.2) 3.0 (76.2) 3.25 (82.5)
1.38 (34.9) 1.5 (38.1) 1.5 (38.1) 1.5 (38.1) 1.5 (38.1) 1.75 (44.5)
16.14 (410) 16.14 (410) 16.14 (410) 16.14 (410) 15.9 (405) 19.7 (500)
24.02 (610) 24 (610) 24 (610) 24 (610) 24.3 (617) 31.5 (800)
Rated operating load



50% tip lbs (kg)
35% tip lbs (kg)
Tipping load lbs (kg)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
2700 (1225) 3400 (1542) 3200 (1451) 3700 (1678) 4500 (2045) 6200 (2812)
1890 (860) 2380 (1079) 2240 (1018) 2590 (1178) 3150 (1432) 4340 (1969)
5400 (2449) 6800 (3084) 6400 (2902) 7400 (3357) 9000 (4091) 12,500 (5670)
Breakout forces



Lift cylinder lbs (kN)
Bucket cylinder lbs (kN)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
6260 (27) 7760 (34.5) 4840 (21.5) 6110 (27.2) 7562 (33.6) 12,084 (53.8)
7270 (32.3) 8700 (38.7) 7360 (32.7) 7360 (32.7) 9188 (41.8) 12,907 (57.4)
Cycle times



Raise sec
Lower sec
Dump sec
Roll back sec
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
3.6 4.4 3.9 4.5 5.1 4.18
1.8 2.6 2.5 2.6 3.5 2.18
2.2 2.6 2.7 2.6 2.7 2.25
1.7 2.0 2.0 2.0 2.0 1.6
Weights



Operating weight lbs (kg)
Shipping weight lbs (kg)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
8270 (3750) 10,000 (4536) 9630 (4370) 9945 (4520) 10,610 (4823) 16,100 (7311)
7970 (3615) 9656 (4380) 9300 (4220) 9615 (4370) 10,267 (4657) 15,800 (7182)
Service Capacities



Fuel tank, gal (L)
Engine oil with filter, qt (L)
System Capacity with filter, qt (L)
DEF tank, gal (L)
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
19.5 (73.8) 25.5 (96.5) 25.5 (96.5) 25.5 (96.5) 25.5 (96.5) 30.8 (116.5)
8.9 (8.5) 8.9 (8.5) 8.9 (8.5) 8.9 (8.5) 8.9 (8.5) 8.9 (8.5)
34 (32.2) 47 (44.5) 47 (44.5) 47 (44.5) 45.4 (48) 42.8 (40.5)
NA 2.8 (10.7) NA NA 2.8 (10.7) 3.3 (12.4)
Lift Style



Lift design
C327

C327
C334

C334
C332

C332
C337

C337
C345

C345
C362

C362
Radial Radial Vertical Vertical Vertical Vertical
