MSRP
* Prices subject to change. Please contact for latest pricing.
Stock status: Call Store for Availability
| Minimum working width |
|---|
| Maximum working width |
| Number of rake wheels |
| Rake wheel bearings |
| Center kicker wheel |
| Rake wheel diameter |
| Tine diameter |
| Tine sets per wheel |
| Rake wheel mounting |
| Rake wheel lift |
| Rake wheel ground pressure |
| Safety chain |
| Transport wheels and tires |
| Tread width |
| Single axle |
| Tandem axle |
| Minimum windrow width |
| Maximum windrow width |
| Transport width |
| Transport length |
| Transport height |
| Rake wheel clearance on headlands |
| Single-side raking |
| Intermediate caster wheel set |
| Windguards |
| Minimum power requirement |
| Required tractor hydraulic connections |
| Hitch |
| Machine weight approx. |
| Rake wheel and frame extension kit |
| Road lights and signaling |
| SR 800 – 17 WHEEL | SR 800 – 19 WHEEL |
|---|---|
| 10′ (3.1 m) | 10′ (3.1 m) |
| 27′ (8.2 m) | 29’6″ (9.0 m) |
| 17 | 19 |
| Tapered roller bearings with grease zerk | Tapered roller bearings with grease zerk |
| N/A | N/A |
| 60″ (1.5 m) | 60″ (1.5 m) |
| 9/32″ (7 mm) | 9/32″ (7 mm) |
| 36 (18 pairs) | 36 (18 pairs) |
| Bolts | Bolts |
| Hydraulic | Hydraulic |
| Right and left side independent adjustable spring suspension | Right and left side independent adjustable spring suspension |
| Optional | Optional |
| 9.5L – 15, 8-ply rating | 9.5L – 15, 8-ply rating |
| 12’4″ (3.8 m) | 12’4″ (3.8 m) |
| – | – |
| Standard | Standard |
| 4′ (1.2 m) | 4′ (1.2 m) |
| 6′ (1.8 m) | 6′ (1.8 m) |
| 12’4″ (3.8 m) | 12’4″ (3.8 m) |
| 28’3″ (8.6 m) | 32′ (9.8 m) |
| 8’3″ (2.5 m) | 8’3″ (2.5 m) |
| 14″ (36 cm) | 14″ (36 cm) |
| Standard | Standard |
| – | – |
| Standard | Standard |
| 80 hp (60 kW) | 80 hp (60 kW) |
| 2 DA | 2 DA |
| Drawbar | Drawbar |
| 6,170 lbs (2,800 kg) | 6,574 lbs (2,982 kg) |
| – | Standard |
| Standard | Standard |
