MSRP
* Prices subject to change. Please contact for latest pricing.
Stock status: Call Store for Availability
The side-delivery design allows you to make multiple passes and combine a large number of windrows into one. However, in very dense crop conditions or for making night windrows to reduce dew on the crop, the GA 6002 can be set to form two windrows on each pass. With the parallelogram-style drawbar tongue, hookup is easy and its high lift height clears most windrows. Long flexible tines touch the crop just once, lifting and placing it neatly into the windrow. For crops such as alfalfa, this gentle handing, in conjunction with being able to rake when the hay is still damp, is especially beneficial as it ensures the leaves will remain intact.
| Working width – includes windrow |
|---|
| Clean swept width |
| Windrow width |
| Transport width |
| Length |
| Transport height |
| Lift height under tines |
| Windrow delivery |
| Single or double windrow |
| Adjustable swath curtain |
| Number of rotors |
| Rotor diameter |
| Number of tine arms per rotor |
| Number of tines per tine arm |
| Fully enclosed gearbox |
| Number of wheels per front rotor |
| Number of wheels per rear rotor |
| Removable tine arms |
| Wheels |
| Working height adjustment |
| Rotor flotation |
| Transport tires |
| Sequential rotor lift |
| PTO speed |
| PTO shaft |
| Overrunning clutch on PTO |
| Setting into transport position |
| Hitch |
| Minimum PTO power requirement |
| Required tractor hydraulic connections |
| Required tractor electrical connections |
| Control box |
| Road lights and signaling |
| Machine net weight approx. |
| Safety chain |
| Check chain |
| GA 6002 |
|---|
| 1 swath 11’6″ – 19′ (3.5 – 5.8 m) 2 swaths 17’9″ (5.4 m) |
| 7′ – 14’9″ (2.1 – 4.5 m) |
| 2’7″ – 4’7″ (0.8 – 1.4 m) |
| 9’8″ (2.9 m) |
| 24′ (7.3 m) |
| – |
| 17″ (43 cm) |
| To left |
| Standard |
| Standard on front and on rear |
| 2 |
| 2 x 8’8” (2.6 m) |
| 10 |
| 3 |
| Standard |
| 4 |
| 4 |
| Fixed |
| 18 x 8.50-8″ |
| Crank (hydraulic option) |
| 3-D terrain following |
| 18 x 8.50-8″ |
| – |
| 540 rpm |
| 1 3/8″ – 6 spline CV PTO |
| Optional |
| Hydraulically controlled |
| Drawbar |
| 40 hp (30 kW) |
| 1 SA + 1 DA |
| 1 – 7-pin signal |
| – |
| Standard |
| 2,778 lbs (1,260 kg) |
| Standard |
| – |
