KUHN FB 3125 Fixed Chamber Round Baler

MSRP

Call for price

* Prices subject to change. Please contact for latest pricing.

Stock status: Call Store for Availability

Engineered for hay and forage producers who demand durability, density and efficiency, the KUHN FB 3125 fixed chamber round baler delivers high-performance baling in a compact 4×4 package. Built with KUHN’s proven PowerTrack rollers and Integral Rotor technology, the FB 3125 ensures consistent bale formation and superior crop flow, even in tough silage or heavy hay conditions. Its robust construction, low-maintenance design make it an ideal choice for livestock operations, custom balers and mid-sized farms looking for increased efficiency and bale quality across a wide range of forages.

SPECIFICATIONS


Bale size – width x diameter
Bale chamber
Transport width
Transport height
Transport length
Electronic monitor
Teardrop plate
Chain lubrication system
Pickup width
Number of pick-up tine bars
Pick-up crop roller
Drop floor technology
Theoretical cutting length
Knife protection
Rotor disengagement
Net storage up to two rolls
Twine storage for 6 rolls
Baling pressure setting
Fast tailgate detection
PTO power requirement
PTO speed
Required tractor hydraulic connections
Wide angle PTO shaft
Drawbar
Road lights and signaling
Minimum machine weight

FB 3125
48″ x 49″ (122 x 125 cm)
18 POWER TRACK rollers
99″ (251 cm) (105″ (267 cm) on 480/45-17 wheels, 107″ (273 cm) on 500/50-17 wheels)
92″ (234 cm)
167″ (423 cm)
VT 30 terminal
Standard
Standard (electric continuous chain oiler with 7 liter reservoir)
91″ (230 cm)
4
Standard
OptiFeed: optional, OptiCut: standard
OptiCut 14: 2.8″ (70 mm)
OptiCut 14: individual spring protected
Manual
1 + 1 storage
2 + 2 storage with optional twine binding system
on machine controlled
Standard (as from 80%)
79 hp (58 kW)
540 rpm
1 single acting and 1 double acting valve
Standard with cam clutch
Standard height adjustable, upper- and lower attachment possibilities
Standard
6,500 lbs – 7,720 lbs (2,950 – 3,500 kg)
