Specs
UPC
193308221809
Starter
Electric
Steering Control
Twin levers with center fixed reference bar for ease of control forward and reverse
Front Caster Tires
13 x 5.0-6, smooth-tread, semipneumatic tires with tapered roller bearings.
Drive Tires
20x10.0-8 Carlisle Turf Master
Parking Brake
Lever-actuated bar brake.
Tractor Frame
Welded, heavy-duty 1.5" x 2.5" tubular steel.
Blade Spindles
No maintenance, sealed and nongreasable spindles; 7.75" diameter cutter housing with 1.75" diameter splined blade driver 1.0"-diameter spindle shaft.
Cup Holder
Yes
Electrical
12-volt battery with 15-amp alternator.
Standard Features
Enhanced Engine Hour Meter
Transmission Speeds
Infinitely Variable
Engine Brand
Kawasaki
Transmission Brand
Hydro-Gear
Engine Model
FX730V
Engine Displacement
726
Transmission
Hydrostatic
Engine Series
V-Twin
Fuel System
Carbureted
Speed
Infinitely variable speed selection 0–8.5 mph (x.x kmph) forward, 0–x.x mph (x.x kmph) reverse
Engine Speed
3,750 rpm
Air Filter
Heavy-duty canister air filtration system
Fuel Capacity
8-gallon (xx.x-L), single fuel tank on LH side.
Drive Description
Two Hydro-Gear 12 cc pumps powering two Parker 14.5 cubic inch motors.
Fuel Type
Gas Carbureted
PTO Engagement
Warner 200 ft-lb clutch
Drive System
HYDRO
Drive Wheel Release
Allows unit movement without engine running.
Fuel Indicator
Yes - Float Gauge
Deck Lift
Single point HOC; with mechanical lift-assist springs.
Carb Compliant
NO
Safety Package
Operator Presence Controls (OPC) with safety interlock system indicators
Deck Style
Floating Deck
Deck Style Description
Full-floating UltraCut Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.
Width / Cutting Deck
52"
Deck Construction
10-gauge top that is formed and continuously seam welded, 7-gauge side skirt
Cutting Heights
1.5" (3.8 cm) to 5.0" (12.7 cm) in 0.25" (0.64 cm) increments adjustable from operator’s platform.
Blade Tip Speed
Approximately 18,500 fpm.
Blades
3 Blades at 18.00" Length
Width
64.79
Height
49.2
Length
65.33
Curb Weight
936
